Required for Use
Electrical Cord for Ranges
Gas Flex Hose for Gas Cooking Appliances
The grates must be properly positioned before cooking. In the proper position, the grates should be flush and level. Improper installation of the grates may result in chipping or scratching of the cooktop.
To ensure proper positioning, align bumpers on grate bottom with the indentations in the cooktop.
The display will flash when powered up or after a power loss. Press the Cancel keypad to clear. When the oven is not in use, the time of day is displayed.
The temperature is preset at Fahrenheit, but it can be changed to Celsius.
The Sabbath mode sets the oven to remain on in a Bake setting until turned off. A Timed Bake can also be set to keep the oven on for only part of the Sabbath. The Oven Control Lockout feature (if present) will be disabled during the Sabbath.
Frozen Bake™ Technology automatically adjusts the manufacturer’s bake time by combining preheating and baking, to deliver great packaged frozen food results without the wait. There are six programmed food options to choose from: Pizza, Lasagna, Nuggets, Fries, Pie, and Meal. The Frozen Bake™ cycles have been customized to work only with these foods. When using Frozen Bake™ Technology, it is important that you follow all manufacturer’s instructions including venting, covering, stirring or placing on a baking sheet to ensure a good result. When cooking frozen meals, only cook items that provide instructions for cooking in a conventional oven. Place your dish in the center of the rack and select one of the rack positions recommended for Frozen Bake in the “Positioning Racks and Bakeware” section and bake only one package or pan at a time. Use the temperature and maximum bake time from the package.
A tone will alert you to check the food for doneness before the cook time is complete and again at the end of the cook time. The display will prompt you to add additional cook time if needed.
When broiling, preheat the oven for 5 minutes before putting food in unless recommended otherwise in the recipe. Position food on grid in a broiler pan, then place it in the center of the oven rack.
The temperature management system electronically regulates the oven heat levels during preheat and bake to maintain a precise temperature range for optimal cooking results. The bake and broil elements cycle on and off in intervals. The bake element will glow red when cycling on; the broil element will not. This feature is automatically activated when the oven is in use.
Before baking and roasting, position racks per the “Positioning Racks and Bakeware” section. When roasting, it is not necessary to wait for the oven to preheat and food may be placed in the oven immediately, unless preheat is recommended in the recipe.
In a convection oven, the fan-circulated hot air continually distributes heat more evenly than the natural movement of air in a standard thermal oven. This movement of hot air helps maintain a consistent temperature throughout the oven, cooking foods more evenly, crisping surfaces while sealing in moisture, and yielding crustier breads.
AquaLift® Technology is an innovative cleaning solution that utilizes heat and water to release baked-on spills from the oven in less than 1 hour. This new cleaning technology is a low-heat, odor-free alternative to traditional self-cleaning options.
|Grate Material:||Porcelain On Cast Iron|
|Grate Styling:||Continuous Grates|
|Oven Door Window Type:||Large|
|Door Swing Option:||Drop Down|
|Depth w/Door Open:||48|
|Controls:||Digital & Mechanical|
|Digital Display Items:||Clock and Timer|
|Number of Oven(s):||1|
|No. of Oven Racks:||2|
|No. of Rack Positions:||7|
|Bake Burner/Element: (BTU/Watts/Kw)||18000 BTU|
|Cleaning Method:||Self Cleaning|
|Cooktop Surface:||Porcelain Coated Steel|
|Product Weight (lbs.)||187|
|Cooktop Features||Control Lockout, LP Convertible, Griddle Included|
|Depth w/Door Open 90 Degrees (in.)||48|
|Appliance Fit Width (in.)||30|
|Manufacturer Warranty||1 Year Limited Warranty|
|Capacity (cu ft)||5.8|
|Grate Material||Porcelain-Enameled Cast Iron|
|Total Capacity (cu. ft.)||5.8|
|Color Finish Name||Black Stainless Steel|
|Number of Elements Burner Cooking Zones||5|
|Number of Elements/Burners||5|
|Hot Surface Indicator||No|
|Cooktop Surface Style||Grate|
|Fuel Type||Natural Gas|
|Number of Oven(s)||Single|
|Appliance Color||Black Stainless Steel|
|Oven Features||Self-Cleaning, Broiler in Oven, Delay Bake/Start, Keep Warm, Speed Cook, LED Display, Fingerprint Resistant Finish|
